Description
The C4 Magnum-GO is designed for all intensity requirements of Fluorescent Penetrant Inspection (FPI) and Magnetic Particle Inspection (MPI). REL’s C4 Magnum-GO inspection lamps contain high flux UV-A and white light LED emitters with built-in static-electric discharge circuits. The C4 Magnum-GO provides a 10-inch diameter of UV-A intensity >1000 µW/cm² at 15 inches. The integral filter in the UV-A emitter limits the visible light to 20 lux (1.86 foot-candles) at 15 inches and 5 lux (0.47 foot-candles) at 36 inches.
The LED white light provides an intensity > 700-foot candles at 15 inches. The lamp’s electrical components are IP67 sealed and passively cooled within an engineered finned housing manufactured from military-grade aluminum. The lamp performs in all environments regardless of ambient conditions. The C4 Magnum-GO LED UV-A with white light will survive the toughest, wettest, and most severe work environments on the planet!
Sleek and rugged design
The LED white light provides an intensity > 700-foot candles at 15 inches. The lamp’s electrical components are IP67 sealed and passively cooled within an engineered finned housing manufactured from military-grade aluminum. The lamp performs in all environments regardless of ambient conditions. The C4 Magnum-GO LED UV-A with white light will survive the toughest, wettest, and most severe work environments on the planet!
- UV-A and white light emitters for darker inspection environments.
- Easy to use one-hand controls with clear indicators for lamp on/off operation.
- Visible Spectrum (white light) LED provides an intensity > 700 foot-candles at 15 inches.
- Engineered fin housing allows for maximum heat transfer in the harshest environments.
- Built-in static-electric discharge unit safety feature.
- AC Power: 120/240V.
- Individual lamp dimensions: 7.6” H x 3.0” W x 4.1” D.
- Individual lamp weight: 1.7 lbs.
- 2-year Warranty.
- Refurbishable.
